ANDREA 100 3000K DIMM (30W+70W) BK
AZ5102
Files to download:
Instrukcje montażu
Karty techniczne
Deklaracja zgodności CE [PL]
Deklaracja zgodności CE [ENG]
3D Models:
Architect’s Zone
Don’t have an account yet? Register now and gain access to the architect’s zone.
You will be able to browse and download product files.
Product Information
Description
Type: PENDANT
Type of light source: LED INTEGRATED
Maximum power: 90W [UP 25W / DOWN 65W]
Energy class: G
Protection class: IP20
Dominant color: BLACK
Main finish: MATTE
Dominant material: ALUMINIUM
Accent material: SILICONE
Ceiling base color: BLACK
Ceiling base height [cm]: 7
Ceiling base width [cm]: 29
Lampshade height [cm]: 4,5
Lampshade width [cm]: 98 / 2
Light source: 2
Lumens [lm]: 4900
Color temperature [K]: 3000
Dimmable: YES
CCT: NO
RGB: NO
CRI [Ra]: ≥ 80
Azzardo Smart app: NO
Remote control: NO
Bluetooth control panel: NO
Bluetooth gateway: NO
Motion sensor: NO
Control options: • TRIAC DIMMER
Control type > For all: TRIAC DIMMER
Voltage: ~ 230V
Protection class (against electric shock): 1
Net weight [kg]: 5,6
Gross weight [kg]: 6,2
Box 1 depth [cm]: 104
